Display parameters
| Transmission frequency | 433.92 mhz |
|---|---|
| Operating temperature | -20℃~ + 80℃ |
| Storage temperature | -30℃~ +85℃ |
| Charging port | USB |
| Charging current | ≤1A |
| Working current | ≤10mA |
| Input voltage | 5V |
| Battery capacity | 600mA |
| Size (L * W * H) | 30*75*29mm |
| Weight | 70.0 g |
Sensor Parameters
| Working Temperature | -40℃ ～ +105℃ |
|---|---|
| Storage Temperature | -40℃ ～ +120℃ |
| Pressure Range | 0~116psi（0~8.0bar） |
| Pressure Precision | ±1.5PSI（±0.1bar） |
| Temperature Precision | ±3℃ |
| Transmitting Power | <10dbm@50Ω |
| Transmitting Frequency | 433.92MHz |
| Battery model | T86XB-WF：CR1632
T86BB-NF+：CR2450 |
| Battery capacity | T86XB-WF：120mA
T86BB-NF+：540mA |
| Battery Life | T86XB-WF：2 years
T86BB-NF+：5 years |
| Size( L*W*H ) | T86XB-WF：H17mm*D24mm
T86BB-NF+：69*32*15mm |
| Weight | T86XB-WF：9.5g
T86BB-NF+：55.0g |
